Dubai Electricity and Water Authority (DEWA) intend to construct a new 400/132kV Substation DBXSHMAL in Al Qusais area. Therefore, a Call has been published for Construction, Supply, Installation, Testing & Commissioning of Canal Gardens (CANLGRDN), Dubai Janoub (DXBJANUB), Dubai Shamal (DXBSHMAL) & Shams (SHAMS) 400/132kV substations and associated modification works.
Technical and Commercial evaluations of received Bids were performed by Energoprojekt ENTEL.
Project Started on 25-02-2018, completion is planned on 24-01-2021 (35 Months)
Services provided
- Preparation of conceptual design report
- Preparation of Tender documents/drawings
- Environmental Impacts Assessment Study
- Bid Evaluation and tender clarifications
- Recommendation of the preferred Bidder to the client
- Design review of the documents/drawings prepared by the Contractors design Vendor approvals and review of vendor drawings.
- Supervisory services for the construction works of all disciplines, testing and commissioning of equipment, auditing of EPC contractor’s claims etc.
- Variation Order approvals and Advising DEWEA on all contractual matters.
- Preparation of Project closure reports.
Technical data
- New indoor 400kV GIS at the Dubai Shamal (DXBSHMAL) 400/132kV Substation site. This provides 12 Nos. circuit-breaker bays in a double Bus bar configuration, arranged as follows:
- Four (4) Transformer (ICT) bays each rated at 1250 A
- Two (2) Bus Coupler bays each rated at 4000 A
- Two (2)Bus Section bays each rated at 4000 A
- Four (4) OHL bays each rated at 3150 A
- New indoor 132kV GIS at the Dubai Shamal (DXBSHMAL) 400/132kV Substation site. This provides 30 Nos. circuit-breaker bays in a double bus bar configuration, arranged as follows:
- Four (4) Transformer (ICT) bays each rated at 2500 A
- Two (2) Bus Coupler bays each rated at 3000 A
- Two (2) Bus Section bays each rated at 3000 A
- Eighteen (18) Cable Feeder bays each rated at 1500 A
- Four (4) Bus Reactor bays each rated at 1500A
- Four (4) ICT 400/132kV, 500MVA transformers supplied and installed to interconnect the 400 kV and 132 kV Substations.
- Four (4) 132kV 40MVAr Bus connected Shunt Reactors supplied and installed to reduce voltage transients.
Client
Dubai Electricity and Water Authority (DEWA)
